Motorola Expert Series User Manual

5-2 CPS Programming Setup
Refer to the CPS online help for detailed tuning procedures.
Figure 5-1 Radio Tuning Setup
5.3 CPS Programming Setup
Refer to online help files for the CPS Programming procedures.
Figure 5-2 CPS Programming Setup
Wattmeter
Audio Generator
Sinad Meter
AC Voltmeter
10 dB Pad
Battery Block
Power
Supply
Audio In
Tx
Rx
Receive
Transmit
RF Generator
RF Adaptor
HLN9756
RIB
RLN4008
RIB Power Supply
RLN4460
Test Box
Rx
Gnd
Data
Tx Data
Radio
Computer Interface
Cable 3080369B72
Program / Test Cable
RKN4074
Service Monitor
or Counter
DB15 DB9
AC Plug
120/230 Vac
3.5 mm to
Ferrule BNC
JMKN4125
+12VDC
0180305G54
Battery
Eliminator
7.5V Reg.
RIB
RLN4008
RIB Power Supply
RLN4460
Test Box
Rx
Gnd
Data
Tx Data
Radio
Battery
Computer Interface
Cable
Program/
AAJMKN4123
Test Cable

Motorola Expert Series Specifications

General

Category	Two-Way Radio
Manufacturer	Motorola
Series	Expert Series
Channels	16
IP Rating	IP54
Power Output	5W (VHF), 4W (UHF)
Operating Temperature	+60°C
