TABLE OF CONTENTS
Operational Safety Guidelines ...................................................3
IMPRES Feature / Benefit Description ......................................4
Operational Characteristics / Differences: .................................5
Battery Lists ...............................................................................6
Power Sources and Motorola Authorized Power Adapters .....10
Operating Instructions .............................................................11
Charging the Batteries ................................................................. 13
Manually Reconditioning the Batteries ........................................ 14
Automatically Reconditioning the Batteries ................................. 14
Manually Terminating the Reconditioning Process ...................... 15
Troubleshooting .......................................................................16
Service .....................................................................................17
Chargers with Display Module (CDM) .....................................17
General Display Information ........................................................ 18
Sequencing Diagrams for IMPRES Batteries .............................. 21
Display Text Orientation .............................................................. 27
IMPRES Adaptive Multi-Unit Charger Operation ......................... 27
Service ......................................................................................... 27
This accessory manual is applicable to the following IMPRES Universal Multi-
Unit chargers:
WPLN4108, WPLN4109, WPLN4110, WPLN4118, WPLN4119, WPLN4120,
WPLN4121, WPLN4123, WPLN4130, WPLN4131, WPLN4132, WPLN4133,
WPLN4134, WPLN4135, WPLN4136
Additionally, this manual includes the following IMPRES Universal Multi-Unit
chargers that are available for the GP Professional Series radios:
WPLN4144, WPLN4145, WPLN4146, WPLN4187, WPLN4188, WPLN4189,
WPLN4190, WPLN4191, WPLN4192, WPLN4193, WPLN4194, WPLN4195,
WPLN4196, WPLN4204, WPLN4205
‘Universal’ denotes that the charger supports multiple radio models and,
through the use of battery adapters, all batteries listed in tables 1 - 10 inclusive.
