7. Choose one of the following options:
If… Then…
If this is dual Solar
Panel deployment,
perform the following actions:
a. Repeat the Solar Panel mounting process in step Step 1 for the
Expansion Solar Panel.
b. Connect the two remaining connectors on the Y-cables to the power
cables on the Expansion Solar Panel.
c. Perform cable management as necessary.
d. Go to Camera Installation.
If this is a single Solar
Panel deployment,
go to Camera Installation.
3.4
Installing AC Power
The AC 120V External Power option requires an existing AC power outlet installed by a certified electrician.
Mounting of the 120V AC Power Adapter and cable management is dependent on the camera mounting
location and distance to the power source.
Prerequisites: Obtain:
● 120V AC Power Adapter
● Zip-Tie (1x)
Procedure:
1. Plug the 120V AC Power Adapter into a furnished AC power outlet.
2. Check the power cable length.
a. Run the AC adapter power cable to the approximate location of the camera.
b. Use a Zip-Tie to secure the end of the cable in place.
3. Go to Camera Installation.
3.5
Installing DC Power
The 12V DC External Power option requires an existing DC power facility installed by a certified electrician. It
is necessary to splice together the wires of the power source and the DC Power Cable. Cable management is
dependent on the camera mounting location and distance to the power source.
Prerequisites: Obtain:
● 12V DC Power Cable
● Wire Snips
● Wire Shrink Wrap or Electrical Tape
Procedure:
1. Splice the conductors from the DC power source to the conductors of the 12V DC Power Cable.
a. Use the Wire Snips to strip the ends of each conductor.
MN010089A01-AD
Chapter 3: Hardware Installation
52
