Motorola Malux MTM5x00 Series

Figure 32: Rear View of the TSCH Cradle with Slim Bracket
1
2
Number Description
1 Bracket Hook
2 TSCH Cradle Locking Slot
4 Pull down the TSCH cradle until the Bracket Hook is fully engaged to the TSCH Cradle Locking
Slot.
68015000181-LB
Chapter 4: Radio Installation
72 Send Feedback
