Connectors and Pin Assignment of Data Expansion Head
Enhanced and Remote Head Enhanced
Figure 57: Data Expansion Head Enhanced – Front View and Connector Location
J302
12
345678
910
1
1425
5
69
113
1 2 3
Number Description
1 10-Pin TELCO Connector, Front View,
CAUTION:
Connector to the Control Head.
2 25-Pin subD Connector
3 9–Pin subD Connector
68015000181-LB
Chapter 5: Connectors and PIN Assignment
