1 - 8 MC1000 with Windows CE 5.0 User Guide
Figure 1-6
Li-ion Battery Removal
AAA Batteries Removal
To remove the AAA batteries:
1. Press the red Power button to turn off the screen and place the mobile computer in suspend mode.
2. Pull back the two battery door latches.
3. Lift the battery door.
4. Remove the three AAA batteries from the mobile computer.
Figure 1-7
AAA Battery Removal
Spare Battery Charging
Use one of two accessories to charge spare Li-ion batteries. See to Chapter 3, Accessories for more information
on spare battery charging.
NOTE Pulling back the left battery door latch places the mobile computer in suspend mode.
