MCS 2000 Models II & III 68P81083C49-B
General Information
With the MCS 2000 you have chosen an excellent
mobile radio. The Motorola warranty for quality guar-
antees the high standard of Motorola products. Your
MCS 2000 radio has left our factory only after exten-
sive tests.
This user guide describes the way a
standard
radio works. Since standard operation may be
changed by programming - both concerning
the
Functions
which the radio includes and the
Buttons
used to activate them - the way your
radio operates may differ from what is
described here.
The radio
display prompts
may be pro-
grammed into the radio in one of a number of
different languages. English is the default lan-
guage and is used to describe the displays in
this user guide.
For further information, contact the person in
charge of your radio system or your local serv-
ice representative.
Functions of the Buttons
Numbers in brackets refer to the illustrations on the
fold out page.
Depending on the keypad ordered with your radio,
refer to either “E” or “I” for the description of the but-
tons:
(A) Radio ON/OFF
and
Volume control
(B) Three-color indicator
Green
, flashing: incoming call or Call Alert Page
Red
, continuous: radio transmits in clear and
secure
Orange
, continuous: system/channel busy or
incoming clear call (secure operation).
Orange
, flashing: incoming secure call (secure
operation).
(C) Display
with symbols and one line (model II) or
two lines (model III) of 14 characters.
(D) Mode selector
(F) Transmit key (PTT)
Push to talk, release to listen.
(G) Microphone connector
(1) Zone select
(2) Monitor
, press button to listen for activity (con-
ventional operation) or
Search
(AMSS/SmartZone operation)
(3) HOME
(4) Secure on/off
(secure operation)
(5) Emergency
(6) External alarm
(7) Telephone interconnect
(8) Scan
(9) Menu
MCS2000 2&3-C UG GB (for US) Page 2 Monday, December 8, 1997 4:21 PM
