MCS 2000 Models II & III 68P81083C49-B
page 5
If additional input is required, use the selector (D) to
select the desired function. Press the select button (13).
A list of potential menu functions is found in the back
of this user guide (page 20).
Adjust Display Intensity
Select the menu
DISP INTENSITY
. Press the select
button (13). The display intensity may then be
adjusted to one of four levels: high, medium, low or
very low, using the selector (D).
Tones On/off
The tones heard every time a key is pressed may be
turned off or on through the menus.
Select the menu
TONES
. Press the select button (13).
The display then shows the present state e.g.
model III model II
Use the mode selector (D) to toggle between “tones
off” and “tones on”. Press the select button (13) when
the desired state is in the display.
Zone and Mode Selection
A mode is a channel or talkgroup and all its related
features. A zone is a grouping of modes that can be
selected by pressing the zone button (1). Then use the
mode selector (D) to display the desired zone e.g.
where the model III display has the zone name in line
one and the channel/talkgroup name in line two. For
model II the zone name is followed by the channel/
talkgroup name. The zone name flashes until you
press the select button (13) to choose it. Then use the
mode selector (D) until the desired talkgroup/channel
is displayed, e.g.
Outgoing Calls
When you have selected zone and mode, you are
ready to transmit.
Lift the microphone out of its holder and press the
PTT (F) while talking, release it while listening. Speak
in a normal tone of voice, keeping a distance of 2-4”
from the microphone. While transmitting the red indi-
cator (B) will light.
