Test Equipment and Service Aids: Portable Programming Cable 2-3
2.3 Portable Programming Cable
Figure 2-1. Portable Programming Cable with TTR (PMKN4128_)
Table 2-3. Pin Configuration of Portable Programming Cable with TTR
CONNECTION
P1 P2 P3 Function
11
VCC(5V)
22
DATA-
33
DATA+
4
BNC Center Pin TTR
5 4 BNC Shell GROUND
“P2”
#1 #4
“P3”
“P1”
#1
#5
#2
#1 #3 #5
#4
