Motorola SL1M - Page 40

3-4 Transceiver Performance Testing: Test Mode
Table 3-3. Test Frequencies
Channel
Selector
Switch
Position
Test
Channel
UHF RX UHF TX VHF RX VHF TX
1 Low Power
9 High Power
TX#1 or #9
RX#1 or #9
403.150 403.150 136.075 136.075
2 Low Power
10 High Power
TX#2 or #10
RX#2 or #10
414.150 414.150 142.575 142.575
3 Low Power
11 High Power
TX#3 or #11
RX#3 or #11
425.150 425.150 146.575 146.575
4 Low Power
12 High Power
TX#4 or #12
RX#4 or #12
436.450 436.450 155.575 155.575
5 Low Power
13 High Power
TX#5 or #13
RX#5 or #13
447.150 447.150 161.575 161.575
6 Low Power
14 High Power
TX#6 or #14
RX#6 or #14
458.150 458.150 167.575 167.575
7 Low Power
15 High Power
TX#7 or #15
RX#7 or #15
469.850 469.850 173.975 173.975
8 Low Power
16 High Power
TX#8 or #16
RX#8 or #16
470.000 470.000 174.000 174.000
Final Draft
