5-26 Disassembly And Reassembly Procedures: Radio Exploded Mechanical Views and Parts Lists
Table 5-3. SL1M Exploded View Parts List
Item Description Part Number
1.0 Product Nameplate, SL1M 33012015035
2.0 Front Kit, Assembly Display, UHF: PMLE5027_
Display, VHF: PMLD4697_
2.1 PTT Paddle Display: HN000352A01
2.2 Front Housing, Assembly Display: PMLN7197_
2.3 Internal Antenna Frame, Assembly UHF: 0104064J35
VHF: 0104064J36
2.4 Audio Jack, Speaker, Micro USB, and
Microphone Flex, Assembly
0104063J28
2.5 Internal Frame Assembly 0104064J28
2.6 Screw, Internal Frame 0378212A02
2.7* Display, Assembly UHF: 0104064J38
VHF: 0104064J99
2.8 Dust Cover, Audio Jack and Micro USB SL000095A01
3.0 Antenna See Accessory Table
4.0 Thermal Pad 7515526H01
5.0 Main PCB, Assembly Display, UHF: PMLE5020_S
Display, VHF: PMLD4696_S
6.0 Back Housing Assembly UHF: PMLE5029_
VHF: PMLD4699_
7.0 Screw, Back Housing FN000069A01
8.0 RF Plug EN000047A01
9.0 Screw Plug EN000037A01
10.0 Battery Door Kit Assembly PMLN7074_
11.0 Battery See Accessory Table
12.0* Display Flex, Assembly 0104063J29
Note: * Item for Display Model only
