Annotation Description
10
Talkgroup Selector
Allows user to scroll through the talkgroups of the current selected folder on Idle
screen.
11
Hybrid Antenna
12
LED Coverage Indicator
Shows the coverage status while transmitting and receiving over the network.
13
Earpiece
The Earpiece is active during low-audio simplex or duplex calls.
14
Proximity Sensor
Disables the display and Touch User Interface during full duplex calls to avoid
unintended presses on the touch buttons.
15
PMOLED Display
The 1.54-inch screen features a monochrome display with a resolution of 128 x
64 pixels. The screen consists of a two-line display area with the top line showing
radio icons and the bottom line showing text display.
16
Touch User Interface
The four touch sensitive menu icons allow access to menu navigation.
• To navigate within the menu hierarchy, press the Up or Down
menu icon.
• To return to the previous menu, press the Back menu icon.
• To select or to enter context-sensitive menus, press the Menu/OK menu
icon.
NOTICE: To turn on the Touch User Interface, press the Power/Sleep/
Wake button. The available navigation icons light up depending on the
context or menu that is displayed.
17
Speaker
Provides good quality high audio during simplex calls.
18
Bottom Microphone
Activated during low-audio duplex calls.
3.4
One-Touch Buttons
The One-Touch Button feature allows you to activate a feature by a long key press of the
programmable button. If an unassigned button is pressed, the radio displays Unassigned Button.
Table 12: One-Touch Button Features
Feature
Description
Add Bluetooth Device Activates scanning for Bluetooth devices.
Bluetooth Smart Proximity
Pairing
Turns Proximity Pairing on or off.
Table continued…
MN002955A01-AA
Chapter 3: Man-Machine Interface
