Motorola StarTAC 3000 Service Manual

6/29/98 15
Manual Test Mode
68# MODEL TYPE Read model type.
Display three radio model bytes: hardware (model), flex
(type), and factory.
69# ID TRANSFER Reserved for Identity Transfer Procedure.
70# & 71# (NOT USED)
72# AUDIO GAIN
ADJUST
APC GAIN RANGE
STEP # PARAMETER (HEX)
00 Max. deviation 0-7
Chan. 991-1023, 1-100
01 Max. deviation 0-7
Chan. 101-322
02 Max. deviation 0-7
Chan. 323-544
03 Max. deviation 0-7
Chan. 545-766
04 Max. deviation 0-7
Chan. 767-866
05 VSP audio path deviation 0-F
06 Mic. audio deviation 0-F
07 DTMF deviation 0-3
08 Data deviation 0-3
09 SAT deviation 0-3
0A Discriminator audio gain 0-F
0B DSAT Phase Mod adjust 0-7
0C Headset Mic Path adjust 0-F
73# RF POWER
LEVEL
ADJUST
RANGE
STEP # POWER LEVEL (HEX)
00 Power Step 0 00-FF
01 Power Step 1 (Step 2.5) 00-FF
02 Power Step 2 00-FF
03 Power Step 3 00-FF
04 Power Step 4 00-FF
05 Power Step 5 00-FF
06 Power Step 6 00-FF
07 Power Step 7 00-FF
08-0B Do Not Adjust
Table 3: Test Commands For Manual Test Mode
Keypad
Entry
Command
Description
Status
Display
Result
