Moxa Technologies EDS-510E Series - Technical Specifications; Technology and Interface Details; Physical and Environmental Characteristics

- 15 -
Specifications
Technology
Standards IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X) and 100BaseFX
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3z for 1000BaseX
Protocols
IGMPv1/v2/v3, GMRP, GVRP, SNMPv1/v2c/v3, DHCP
Server/Client, DHCP Option 66/67/82, BootP, TFTP,
SNTP, SMTP, RARP, RMON, HTTP, HTTPS, Telnet, SSH,
Syslog, EtherNet/IP, PROFINET, Modbus/TCP, SNMP
Inform, LLDP, IEEE 1588 PTP V2, IPv6, NTP
Server/Client
MIB MIB-II, Ethernet-Like MIB, P-BRIDGE MIB, Q-
BRIDGE
MIB, Bridge MIB, RSTP MIB, RMON MIB Group 1, 2, 3,
9
Flow Control
IEEE 802.3x flow control, back pressure flow control
Interface
RJ45 Ports
7-port 10/100BaseT(X), 3-port 10/100/1000BaseT(X)
auto negotiation speed
Fiber Ports
3-port 100/1000BaseSFP slot
USB Ports
USB console port (type B connector)
USB storage port (type A connector)
Button
Reset button
LED Indicators PWR1, PWR2, FAULT, STATE, 10/100M (TP port),
100/1000M (Gigabit port), MSTR/HEAD, CPLR/TAIL
Alarm Contact
1 relay output with current carrying capacity of 1 A @
24 VDC
Digital Input
1 input with the same ground, but electrically isolated
from the electronics.
+13 to +30V for state “1”
-30 to +3V for state “0”
Max. input current: 8 mA
Power
Input Voltage
12/24/48/-48 VDC, redundant dual inputs
Input Current
0.68 A @ 24 V
Connection
2 removable 4-contact terminal blocks
Overload Current
Protection
Present
Reverse Polarity
Protection
Present
Physical Characteristics
Housing
Metal, IP30 protection
Dimension
79.8 x 135 x 116 mm (3.13 x 5.31 x 4.57 in)
Installation
DIN-rail mounting, wall mounting (with optional kit)
Environmental Limits
Operating
Temperature
-10 to 60°C (14 to 140°F) for standard models
-40 to 75°C (-40 to 167°F) for T models
Storage
Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity
5 to 95% (non-condensing)
Altitude
Up to 2000m
Note: Please contact Moxa if you require products
