Moxa Technologies EtherDevice EDS-510A Series Hardware Installation Guide

- 14 -
Off
When the EDS-510A disables the
coupling function.
On
TP port’s 10 Mbps link is active.
Blinking
Data is being transmitted at 10
Mbps.
10M
(TP)
GREEN
Off
TP port’s 10 Mbps link is inactive.
On
TP port’s 100 Mbps link is active.
Blinking
Data is being transmitted at 100
Mbps.
100M
(TP)
GREEN
Off
TP port’s 100 Mbps link is inactive.
On
TP/SFP port’s 1000 Mbps link is
active.
Blinking
Data is being transmitted at 1000
Mbps.
1000M
(TP/SFP)
GREEN
Off
TP/SFP port’s 1000 Mbps link is
inactive.
Specifications
Technology
Standards IEEE802.3, 802.3u, 802.3x, 802.1D, 802.1w,
802.1Q, 802.1p, 802.1X, 802.3ad, 802.3z
Protocols IGMP V1/ V2 device, GMRP, GVRP, SNMP
V1/V2c/V3, DHCP Server/Client, BootP, TFTP,
SNTP, SMTP, RARP, RMON and EDS-SNMP
OPC Server Pro (optional)
MIB MIB-II, Ethernet-like MIB, P-BRIDGE MIB,
Q-BRIDGE MIB, Bridge MIB, RSTP MIB, RMON
MIB Group 1,2,3,9
Interface
RJ45 Ports 10/100/1000BaseT(X) auto negotiation speed, F/H
duplex mode, and auto MDI/MDI-X connection
Fiber Ports optional 1000BaseSX/LX/LHX/ZX (LC connector)
Console Port RS-232 (10-pin RJ45)
LED Indicators PWR1, PWR2, FAULT, 10/100M (TP port),
1000M, MSTR/HEAD, CPLR/TAIL
Alarm Contact Two relay outputs with current carrying capacity of
1A @ 24 VDC
Digital Input Two inputs with the same ground, but electrically
isolated from the electronics
• For state “1”: +13 to +30V
• For state “0”: -30 to +3V
• Max. input current: 8 Ma
