MPP Solar PIP 1624 User Manual

9
20
Backlight control
Backlight on
(default)
Backlight off
25
Record Fault code
Record enable
Record disable (default)
Display Setting
The LCD display information will be switched in turns by pressing “UP” or “DOWN” key. The selectable
information is switched as below order: battery voltage, output voltage, output frequency, load percentage,
load in Watt, load in VA.
Selectable information
LCD display
Battery voltage/Output voltage
(Default Display Screen)
Battery voltage=25.5V, output voltage=230V
Output frequency
Battery voltage=25.5V, Output frequency=50Hz
Load percentage
Battery voltage=25.5V, Load percentage=70%
Load in VA
When connected load is lower than 1kVA, load in
VA will present xxxVA like below chart.
When load is larger than 1kVA (≧1KVA), load in
VA will present x.xkVA like below chart.
