BMS RS-485 Card/Box Quick Guide
V.1.3
2. Unpacking and Overview
2-1. Package Contents
Before installation, please inspect the unit. Be sure that nothing inside the package is damaged.
You should have received the following items inside of package:
RS485 Card Package Items:
RS485 card RJ45 cable Manual
Note: This supplied RJ45 cable is custom-made.
RS485 Box Package Items:
RS485 box RJ45 cable RS232 cable Manual
Note: This supplied RJ45 cable is custom-made.
2-2. Product Overview
RS485 card:
RS-485 port
Golden finger(RS-232 port)
Resistance switch
Communication switch
