Accessories
QUANTITYPART LOOKS LIKE...
Optional
Parts
Screws to ecure
remote controller
holder (optional)
Remote Control
Holder (optional)
2
1
Transfer Connector
(packed with the
indoor or outdoor unit,
depending on model)*
1 per
indoor unit
1 - 5 pieces
for outdoor unit,
depending on
model
Parts must be purchased
separately. Consult the dealer
about the proper pipe size of
the unit you purchased.
Liquid side
Gas side
Ø1/4 in (6.35 mm)
Ø3/8 in (9.52 mm)
Ø3/8 in (9.52 mm)
Ø1/2 in (12.7 mm)
Ø5/8 in (16 mm)
Ø3/4 in (19 mm)
Connecting Pipe
Assembly
Note: Illustrations are for explanatory purposes only - The actual shape and size may vary.
*Pipe size may differ from appliance to appliance. To meet different pipe size requirements, sometimes a
transfer connector is needed so the pipes can be properly connected to the unit.
To Next Page
