MrCool Olympus Series User Manual

Page 22mrcool.com
5
Indoor Unit Installation
Installation Summary - Indoor Unit
Select Installation
Location
Attach Mounting
Plate
Determine Wall
Hole Position
1
2
3
Drill Wall Hole
4
90.55 in (2.3 m)
4.75 in
(12 cm)
Distance from ceiling is
determined by the
installation method.
Mount Indoor Unit
STEP
8
Wrap Piping and Cable (not applicable
for some locations in North America)
Connect Piping
& Drain Hose
Prepare Drain Hose
Connect Wiring
(not applicable for some
locations in North America)
4 5 6
7 8
9
4.75 in
(12 cm)
FROM EDGE TO HOLE CENTER:50mm
FROM EDGE TO HOLE CENTER:100mm
150
100
100
100
50
50
50
2
2
2
4
4
4
6
RECOMMAND
LIQUID
GAS
BUBBLE
LEVEL
mm
inch
mm
inch
