Bolt™ Jr+ Quick Start Guide
9
3. Lower the base completely so it is resting on both wings. Secure the
weight plates using the 2xM10 screws on either plate. The screws
should be wedged to the ground to secure the weight plate
completely.
4. At this point, you can remove the castor wheels.
5. Attach the bridges with two weight plates on one side using the
4xM10 screws that attach to the weight plates and 2xM10 screws
that attach to the pedestal base.
Repeat this to secure the bridge on the opposite side.
