Bolt™ Jr+ Quick Start Guide
20
Connecting the cables (Bolt Jr+ on Track)
Cable
wrap
VIDEO 1
48V OUT
VIDEO 2
ETH*
*One Ethernet (ETH) port
is for network connection
to the track motor
controller and to the
Ulti-box for LCMs via the
Mitsubishi arm. Another
ETHERNET goes to the
Mitsubishi CR800 in the
base only, which controls
the arm.
POWER
E
THERNE
T F
or C
amera
ETH*
E-STOP
C
AMER
A PO
WER
C
AMER
A E
TH
UL
TI E
TH*
UL
TI PO
WER 48V
VIDEO 1
VIDEO 1
ETH*
Single phase
AC 200 to
230V
