Bolt™ Jr+ Quick Start Guide
45
Bolt™ Base Cavities Dimension
Dimensions in Transport position
Bolt Jr+ on Track
Width 1.5m x Depth 1.65m x Height 1.40m
Power Requirements
Power supply: Single phase Line+Neutral+Earth
Voltage: 200-230 Volts with 10% tolerance
Current: 2x16A; Peak current: 22.5A
Frequency: 50-60 Hz
The CR800 controller is supposed to be installed and used in the
customer’s system. Supply the primary power of the controller from
system. In addition, provide a safety device (eg earth-leakage current
breaker) that can shut off the power of the controller in the customer’s
187mm 180mm 187mm
