MRMC CINEBOT Bolt Jr+ - Appendix 2 Specifications; Rig Weights

Bolt™ Jr+ Quick Start Guide
43
Bolt™ Jr+ Quick Start GuideBolt™ Jr+Quick Start Guide
Appendix 2 Specifications
Rig Weights
Dimensions Bolt Jr+ on Track Bolt Jr+ on
Pedestal
Total weight 390kg 262kg
Weight- Arm 132kg 132kg
Weight - Base 258kg
(including castor
wheels and
power supply
unit)
130kg
(including
weight plates,
castor wheels,
bridges and
weight buckets)
Weight - anchor weights for track
(when track is not bolted to the
ground)
4x140kg -
Weight - Anchor weights for each
side of base when base not secured
to ground
- 2x140kg (not
included in total
weight above)
Maximum camera payload 10kg (28.6lbs) 10kg (28.6lbs)
