Bolt™ Jr+ Quick Start Guide
23
Bolt Jr+ arm connectors for Ulti-box and camera
The connections that go through the Bolt Jr+ arm are shown below. These
are for the Ulti-box mounted on the arm, and for the camera that you
mount in the cage at the end of the arm.
POWER output:
48 Volts DC
POWER
input: 24-48
Volts DC
ETHERNET
Video 1
Video 2
Ulti-box, which provides various
connectors for camera and lens
controls. For details see Ulti-box
connector summary on page 36.
for camera
ETHERNET
for Ulti
ETHERNET for
Ulti box
