Bolt™ Jr+ Quick Start Guide
11
Mounting the Castor Wheels (Bolt™ Jr+ On
Pedestal)
If you need to move the Bolt Jr+ on Pedestal around, use the following
procedure to mount the castor wheels:
1. Remove the bridge plates.
2. Slide one castor wheel into the base ensuring that edge of the plate
in the wheel assembly is inserted in the slot in the base.
Castor wheel Base (Bottom)
XXXX
X
X
