3. POWER DC input for the Ulti-box and its attached devices. The
standard unit uses a power input of 24-36 Volts. The high-power
variant (marked HV, for High Voltage) uses 24-48 Volts. For pin-out
information see Power connector on page 39.
4. CAM ACC Camera Accessory input/output connector. It has pins for
three stepper motors, two serial lens controls, two trigger in
controls, and two trigger out controls. For pin-out information see
Camera Accessory connector on page 39.
5. DATA DataLink In (Up Link) connector for controlling the Ulti-box
and its attached devices using a DataLink connection, as an
alternative to an Ethernet or Serial RS232 connection. You connect
this to a device that is further up the DataLink daisy-chain, such as:
The DATA OUT (or DOWN LINK) connector on a controller
such as the MSA-20 Handwheels or Large Format Panel (LFP).
The RIG/HEAD connector on an RT-14 interface box which is
in turn connected to a PC running Flair Motion Control
Software.
Note that because there is no DataLink Out connector on the
Ulti-box, the Ulti-box must be connected at the end of the DataLink
daisy-chain rather than the middle. For pin-out information see
Data In connector on page 40.
6. ETHERNET RJ45 connector for controlling the Ulti-box and its
connected devices from a Flair PC. This Ethernet port is rated at 100
Mbits/sec but can operate at lower speeds of 10 Mbits/sec or less.
7, 8. ZOOM, FOCUS connectors for external servo LCMs mounted on
the camera platform. For pin-out information see Servo motor
connector on page 38.
9. TILT connector for a Tilt servo motor on a head. For pin-out
information see Servo motor connector on page 38.
10, 11. AUX-1, AUX-2 connectors for control of auxiliary servo motors.
For pin-out information see Servo motor connector on page 38.
Note
Connectors 1, 7, 8, 9, 10 and 11 are identical and are labelled only for
ease of use.
