7.1.2 Junction Box Typ S47K and X Series AL Junction Box
Manufacturer MSA Europe GmbH
Schlüsselstr. 12,
CH - 8645 Rapperswil-Jona
Product Junction Box Typ S47K and X Series AL Junction Box
EC-Type Examination Certificate BVS 10 ATEX E 066X (DEKRA Testing and Certification GmbH)
Standards EN IEC 60079-0 :2018, EN 60079-1 :2014,
EN 60079-7 :2007, EN 60079-31 :2014
Performance see MSA Controller together with sensor serie 47K
Marking cable gland: NPT ¾” or M25 x 1,25
II 2G Ex db IIC T4/T6 Gb
II 2G Ex e IIC T4/T6 Gb
II 2D Ex tb IIIB T85 °C / T135 °C Db IP6X
Cable gland type HSK-M-Ex-d T4 -50 °C ≤ Ta ≤ +80 °C
T6 -50 °C ≤ Ta ≤ +40 °C
T85 °C -50 °C ≤ Ta ≤ +40 °C
T135 °C -50 °C ≤ Ta ≤ +80 °C
Cable gland type 8161/5-M25-17 T4 -40 °C ≤ Ta ≤ +70 °C
T6 -40 °C ≤ Ta ≤ +40 °C
T85 °C -40 °C ≤ Ta ≤ +40 °C
T135 °C -40 °C ≤ Ta ≤ +80 °C
Special conditions: The connection cable has to be appropriate for the +80 °C ambient temperature
range.
For group III application, the apparatus has to be installed in such a way that
process-related electrostatic charges, e.g. caused by media passing by, can be
excluded
Quality Assurance Notification 2813 (CSA Group Netherlands B.V.)
Year of Manufacture see label
Serial Nr. see label
25 Series 47K GB
7 Markings, Certificates, and Approvals
