7.2 According to IECEx
Manufacturer MSA Europe GmbH
Schlüsselstr. 12,
CH - 8645 Rapperswil-Jona
Product Junction Box Typ S47K and X Series AL Junction Box
IECEx-Type Examination
Certificate
IECEx BVS 12.0057 X (DEKRA Testing and Certification GmbH)
Standards IEC 60079-0 :2011, IEC 60079-1 :2014,
IEC 60079-7 :2006, IEC 60079-31 :2013
Marking cable gland: NPT ¾” or M25 x 1,25
Ex db IIC T4/T6 Gb
Ex e IIC T4/T6 Gb
Ex tb IIIB T85 °C / T135 °C Db IP6X
Cable gland type HSK-M-Ex-d T4 -50 °C ≤ Ta ≤ +80 °C
T6 -50 °C ≤ Ta ≤ +40 °C
T85 °C -50 °C ≤ Ta ≤ +40 °C
T135 °C -50 °C ≤ Ta ≤ +80 °C
Cable gland type 8161/5-M25-17 T4 -40 °C ≤ Ta ≤ +70 °C
T6 -40 °C ≤ Ta ≤ +40 °C
T85 °C -40 °C ≤ Ta ≤ +40 °C
T135 °C -40 °C ≤ Ta ≤ +80 °C
Special conditions: The connection cable has to be appropriate for the +80 °C ambient temperature
range.
For group III application , the apparatus has to be installed in such a way that
process-related electrostatic charges, e.g. caused by media passing by, can be
excluded
Quality Assurance Notification 2813 (CSA Group Netherlands B.V.)
Year of Manufacture see label
Serial Nr. see label
7.3 Special Conditions for SIL 2 According to TUV Certificate 968 / EZ 392.00/09
Safety relevant parameters for Sensor Type 47K-PRP at 25 °C
amb
and for 47K HT PRP at 120 °C
amb
:
Type A
Structure 1oo1
HFT 0
PFD 1,3 x 10
-3
HFT 1
GB Series 47K 26
7 Markings, Certificates, and Approvals
