GB
DESCRIPTION MSA
10 Series 47K Gas Detector [SIL 2]
Operating temperature range PRP- sensor
Extended range *)
-25 °C to +55 °C
-40 °C to +55 °C
HT-PRP sensor -40 °C to +160 °C
Operating humidity range 5% to 95% RH non-condensing
Operating pressure range
800–1200 hPa
Air velocity Air velocity 0–6 m/s
[with duct mount flange: 0.5–20 m/s]
Poison resistance
PRP sensor and HT-PRP sensor:
10 ppm HMDS for 40 min.
[max. signal loss 5% of reading]
Dimension Ø 36 x 56 mm
Weight < 230 g
Material
St. St. 316
Accessory thread M36 x 1.5 mm
Sensor to junction box ¾” NPT or M25 x 1.5 mm
*) Extended range: The sensor extended temperature range is greater than the maximum specified in
EN 60079-29-1. It is therefore strongly recommended that if used above +55 °C or below -25 °C the
sensor is calibrated at the operating temperature.
**) The storage temperature range is also valid for spare parts and accessories
