ORDERING INFORMATION MSA
34 Series 47K Gas Detector [SIL 2]
8. Ordering Information
8.1. Gas Detector (Sensor + Junction Box)
Description Thread Junction Box Type Part-No.
Detector Series 47K-PRP
Screw terminals
M25 x 1.5 Ex e 10114106
Detector Series 47K-PRP
Screw terminals
¾“ NPT Ex d 10114107
Detector Series 47K-PRP
Housing with pushbutton,
Screw terminals
M25 x 1.5 Ex e 10084465
Detector Series 47K-PRP
Spring terminals
M25 x 1.5 Ex e 10114109
Detector Series 47K-PRP
Spring terminals
¾“ NPT Ex d 10114110
8.2. Gas Detector, Calibrated with Certified MSA Gas Controllers
Description Thread Part-No.
Detector Series 47K-PRP
Screw terminals
M25 x 1.5 10123076
Detector Series 47K-PRP
Spring terminals
M25 x 1.5 10123095
Detector Series 47K-PRP
Spring terminals
¾“ NPT 10178833
Detector Series 47K-PRP
Screw terminals
¾“ NPT 10178834
8.3. Sensor
Description Material Thread Part-No.
Sensor Series 47K-PRP St.St. 316 M25 x 1.5 10048118
Sensor Series 47K-HT-PRP St.St. 316 M25 x 1.5 10147537
Sensor Series 47K-PRP St.St. 316 ¾“ NPT 10048272
Sensor Series 47K-HT-PRP St.St. 316 ¾“ NPT 10147542
