MARKINGS, CERTIFICATES AND APPROVALS MSA
30 Series 47K Gas Detector [SIL 2]
7.1.2 Junction Box Typ S47K and X Series AL Junction Box
Manufacturer : MSA Europe GmbH,
Schlüsselstr. 12,
CH - 8645 Rapperswil-Jona
Product :
Junction Box Typ S47K and X Series AL Junction Box
EC-Type
Examination
Certificate
: BVS 10 ATEX E 066X
Standards : EN 60079-0 :2012 + A11 :2013, EN 60079-1 :2014,
EN 60079-7 :2007, EN 60079-31 :2014
Performance : see MSA Controller together with sensor serie 47K
Marking
cable gland: NPT ¾” or M25 x 1,25
II 2G Ex db IIC T4/T6 Gb
II 2G Ex e IIC T4/T6 Gb
II 2D Ex tb IIIB T85 °C / T135 °C Db IP6X
Cable gland type
HSK-M-Ex-d
T4 -50 °C ≤ Ta ≤ +80 °C
T6 -50 °C ≤ Ta ≤ +40 °C
T85 °C -50 °C ≤ Ta ≤ +40 °C
T135 °C -50 °C ≤ Ta ≤ +80 °C
Cable gland type
8161/5-M25-17
T4 -40 °C ≤ Ta ≤ +70 °C
T6 -40 °C ≤ Ta ≤ +40 °C
T85 °C -40 °C ≤ Ta ≤ +40 °C
T135 °C -40 °C ≤ Ta ≤ +80 °C
Junction Box Typ S47K with push button M25 x 1,5
II 2G Ex e IIC T4/T6 Gb
II 2D Ex tb IIIB T85 °C / T135 °C Db IP6X
T4 -20 °C ≤ Ta ≤ +50 °C
T6 -20 °C ≤ Ta ≤ +40 °C
T85 °C -20 °C ≤ Ta ≤ +40 °C
T135 °C -20 °C ≤ Ta ≤ +50 °C
Special
conditions:
The connection cable has to be appropriate for the +80 °C
ambient temperature range.
For group III application, the apparatus has to be installed in such a
way that process-related electrostatic charges, e.g. caused by media
passing by, can be excluded
Quality Assurance Notification : 0158
Year of Manufacture : see label
Serial Nr. : see label
