MSA 47K Series User Manual

GB
MSA ORDERING INFORMATION
Series 47K Gas Detector [SIL 2] 35
8.4. Junction Box
Description Material For use with Senso
r
Part-No.
Ex e, 2 x M25 x 1.5
Screw terminals
Aluminium 47K-PRP 10114111
Ex e, 2 x M25 x 1.5
Spring terminals
Aluminium 47K-PRP 10114114
Ex e, 2 x M25 x 1.5,
1 x M22, with pushbutton
Screw terminals
Aluminium 47K-PRP 10114113
Ex d, 2 x ¾” NPT
Screw terminals
Aluminium 47K-PRP 10114112
Ex d, 2 x ¾” NPT
Spring terminals
Aluminium 47K-PRP 10114115
Junction Box ATEX 100 °C Aluminium 47K-HT-PRP 10151980
8.5. Accessories
Description Material Part-No.
Calibration cap Plastic 10049316
Weather protection cap/hose connection St.St. 316 10051623
Weather protection cap/ 1/8” pipe connection St.St. 316 10051731
Flow through adapter St.St. 316 10051625
Flow through adapter Aluminium 10051626
Duct mount flange St.St. 316 10112790
Wall mounted bracket, Sensor S47K-HT/ -HT-PRP St.St. 316 10048829
S47K adapter plate St.St. 316 10105760
Remote calibration adaptor St.St. 316 10150921
Pipe mounting kit Aluminium 10113032
Note: The pipe mounting kit (P/N 10 113032) is not included in the
EC-Type Examination Certificates DMT 01 ATEX G 001 X,
BVS 03 ATEX G 010 X and DMT 03 ATEX G 003 X
