GB
MARKINGS,
CERTIFICATES A
ND A
PPROVALS
MSA
32
Series 47K Gas
Detector [SIL
2]
7.3.
Special Conditions for SIL 2
According to TUV Certificate 9
68 / EZ 392.00/09
Safety relevant parameters for
Sensor Type 47K-PRP at 25 °C
amb
and for
47K-HT-PRP at 120 °C
amb
:
Ty
pe A
Structure 1oo1
HFT 0
PFD
1,3 x 10
-3
HFT 1
PFH
1,9 x 10
-7
SFF 75,8%
MTBF 272946
h
λ
tot
3664 fit
λ
D 1832
fit
λ
DU 886
fit
λ
DD 946
fit
MTTR 72
h
31
33
Table of Contents
Default Chapter
3
Table of Contents
3
1 Safety Regulations
6
Correct Use
6
Liability Information
6
Application, Advice and Restrictions
7
2 Description
8
General
8
Principle of Operation
9
Technical Specification
9
3 Installation
11
Installation - Step by Step
11
Unpacking
11
General Installation Instructions for Achieving EMC Compliance
11
Recommended Torque and Terminal Sizes
12
Electrical Connection to the Control Unit
13
Junction Box Terminals
13
Maximum Cable Length
13
Electrical Connections
14
4 Start-Up
14
5 Maintenance and Service
15
Calibration
15
Zero Calibration
16
Span Calibration
16
Calibration with Accessories
16
Sensor Replacement
17
Series 47K-PRP and Series 47K-HT-PRP
18
Ht-Prp
19
Prp
19
6 Accessories
22
Calibration Cap
22
Weather Protection Cap
22
Flow through Adapter / Pump Adapter
23
Duct Mount Flange
24
Pipe Mounting Kit
25
Mounting Kit for Pipes with a Diameter of up to 50 MM
25
Mounting Kit for Pipes with a Diameter from 50 MM to 150 MM
26
Remote Calibration Adaptor (Calgard)
26
Installation
27
Operation
28
7 Markings, Certificates and Approvals
29
According to the Directive 2014/34/EU [ATEX]
29
Series 47K-PRP, Series 47K-HT-PRP
29
Junction Box Typ S47K and X Series al Junction Box
30
According to Iecex
31
Special Conditions for SIL 2 According to TUV Certificate 968 / EZ 392.00/09
32
8 Ordering Information
34
Gas Detector (Sensor + Junction Box)
34
Gas Detector, Calibrated with Certified MSA Gas Controllers
34
Sensor
34
Junction Box
35
Accessories
35
9 Dimensions
36
Gas Detector (Ex E Junction Box)
36
Gas Detector (Ex D Junction Box)
37
S47K Adapter Plate (Junction Box)
38
Wall Mounted Bracket, Sensor 47K-HT-PRP
38
Junction Box ATEX 100 °C; Sensor 47K-HT-PRP
39
Pipe Mounting Kit
40
Mounting Kit for Pipes with a Diameter of up to 50 MM
40
Mounting Kit for Pipes with a Diameter from 50 MM to 150 MM
41
Remote Calibration Adaptor
42
10 Wiring Diagrams
43
MSA Control Unit SUPREMA
43
Series 47K-PRP/-HT-PRP [3-Wire]
43
Series 47K-PRP/-HT-PRP [5-Wire]
44
MSA Control Unit 9010 / 9020 Series
44
Series 47K-PRP/-HT-PRP [3-Wire] Channel a
44
Series 47K-PRP/-HT-PRP [3-Wire] Channel B
45
MSA Control Unit Gasgard XL
45
Series 47K-PRP [3-Wire]
45
Series 47K-HT-PRP
46
Wiring Diagram Sensor 47K-HT-PRP with Junction Box ATEX 100 °C
46
11 Appendix
47
Discontinued Gas Detectors
47
K-Ht
48
