Appendix
Control Unit Models 9010 LCD and 9020 LCD
77
GB
Conditions for
use:
Assembly: Wall-mounted/assembly clip
Sensor can be remote sensor
Protection: IP 66/IP 67 EN 60529
Explosion protection:
Housing
DMT 02 ATEX E 202 X
Ex II 2G EEx d IIC T5
–40 °C < Ta +60 °C/+45 °C
Explosion protection:
Sensor
DMT 02 ATEX E 202 X
Ex II 2G EEx d IIC T4
-40 °C < Ta +60 °C/+45 °C
Temperature: -40 °C bis +60 °C type-specific
Humidity: 15 – 95 % relative humidity; non-condensing
Pressure: 950 – 1,100 hPa
Weight: approx. 4.7 kg
Dimensions [W x D x H]: 160.3 x 99.3 x 261.1 mm
Housing material: Stainless steel [ASMT 316/DIN 1.4401]
For further details see the Operating and Maintenance Instructions.
Part No.: 10046690
