Fire-fighting Helmets / Preventive care, control
and maintenance
Version 7a/ May 2010 Page 36/36
Remove the shell straps pulling the 4 clips off the shell (pull to the outside)
Remove the chinstrap pulling the 2 clips off the shell (pull to the inside)
Shell
Same control procedure as for a F1 painted shell.
Re-assembling the helmet
Assemble the shell straps and the chinstrap
Pre-position the chisntrap interface at the rear, it will be used as a guide for the complete
reassembling procedure
Attach the 4 straps clips (the shortest straps are in the front)
Attach the chinstrap clips, leaving the adjustment points on the outside
Check the straps are not twisted, the chisntrap lower strap being inserted into the shell straps
center.
Remove the chinstrap rear interface and insert the ratchet using the clips (rear and front)
Place the chinstrap interface between the headband and the neck pad and attach it to the
shell. Install the neck pad to lock the chinstrap.
