Fire-fighting Helmets / Preventive care, control
and maintenance
Cradle assembly
Ratchet Cradle
References GA3223 – F1SF Ratchet Cradle
GA1067 – Rear interface for Ratchet Cradle
GA3242 – Front interface for Ratchet Cradle
Insert the 2 front clips (front interface) in the inner shell slots, the 2 other clips being located
under the slots (height adjusment is made using these 2 lower clips)
Version 7a/ May 2010 Page 31/36
