MSA G1 SCBA - Page 69

69
Cylinders
G1 SCBA 2018 Edition
US
For cylinders with retainers already installed, use the following MSA part numbers.
(6) Hold the cylinder valve assembly tightly and connect the male
adapter to the valve.
(7) Use a torque wrench to tighten the adapter to 13 – 15 ft·lbf
(18 – 20 N·m).
P/N NIOSH Service Life Rating Pressure
G1 Cylinders c/w QC and Air, Packaged
10175706 30 minutes 2216 psig
10175707 30 minutes 4500 psig
10175708 45 minutes 4500 psig
10175709 45 minutes 4500 psig
10175710 60 minutes 4500 psig
10156427-SP 30 minutes 5500 psig
10156428-SP 45 minutes 5500 psig
10156429-SP 60 minutes 5500 psig
P/N NIOSH Service Life Rating Pressure
G1 Cylinders c/w QC and Less Air, Packaged
10175711 30 minutes 2216 psig
10175712 30 minutes 4500 psig
10175713 45 minutes 4500 psig
10175714 45 minutes 4500 psig
10175715 60 minutes 4500 psig
10181628 30 minutes 5500 psig
10181629 45 minutes 5500 psig
10181630 60 minutes 5500 psig
