Description

G1 Integrated SCBA System

2.1.1 Mask Versions

Harness Versions

The mask is available with different head harnesses; Kevlar (textile) 4-point or rubber (5-point).

The rubber head straps are numbered to indicate the correct tightening sequence.

Fig. 2 Kevlar (textile) harness

Fig. 3 Rubber harness
