9.8 Button Functions
RESET Buttons (green)
Pressing either button performs the following, depending on context:
Single press to:
• Activate the backlight and refresh the HUD (when in intermittent mode)
• Toggle between primary and second screen
Double press to:
• Reset motion pre-alarm (or shake control module to reset)
• Reset motion full alarm
• Confirm evacuation
• Turn off device (when below 15 bar)
• Clear primary alarms
ALARM Button
Activates full alarm by pressing and holding the ALARM button. This will occur when either the
unit is OFF or ON.
9.9 Turning OFF the Control Module
(1) Upon returning to fresh air, close the cylinder valve completely and release all pressure from
the SCBA.
(2) When the pressure falls below 15 bar, turn the control module off by double pressing the
reset button (green).
The shutdown sequence will display on the screen and the lights on the control module and
the power module will stop flashing.
Both reset buttons have the same function, instead of pressing one button twice when
advised.
