MSA G1 - Hose Connection Procedure

76
Buddy Breather
GB
G1 Integrated SCBA System
17.5 Hose Connection Procedure
NOTE: Each manifold has both male and female quick-connect fittings to either supply or receive
air.
(1) Open up the snaps and hook and loop fastener on
the flap of the waist-mounted storage pouch.
(2) Locate the manifold end of the emergency
breathing hose and remove it from the pouch.
(3) Remove the dust cover from the quick-connect
fittings on the donor’s manifold.
(4) Open up the snaps and hook and loop on the flap of
the receiver’s waist-mounted storage pouch.
(5) Locate the manifold end of the emergency
breathing hose and remove it from the receiver’s
pouch.
(6) Connect the donor’s and receiver’s manifold blocks
using a male and female quick-connect fitting with a
single action.
