MSI G4101 - M2_1~2: M.2 Slots (M Key, Pcie 3.0, 22110; 2280); Installing M.2 SSD

22
Storage Connectors
M2_1~2: M.2 Slots (M Key, PCIe 3.0, 22110/ 2280)
Please install the M.2 solid-state drive (SSD) into the M.2 slot as shown below.
Installing M.2 SSD
⚽
Video Demonstration
Watch the video to learn how to
Install M.2 SSD.
2. Set the M.2 riser screw at
the appropriate location
based on the length of
your M.2 SSD.
3. Insert your M.2 SSD
into the M.2 slot at a
30-degree angle.
4. Secure the M.2 SSD in
place with the supplied
M.2 screw.
1. Loosen the M.2
riser screw from the
motherboard.
30°
Supplied M.2 screw
