1-10
1.3 Thermal Solution
To prevent the system from overheating, we have adopted a specially de-
signed CPU cooler and multiple ventilation holes for better cooling effects.
The specially designed CPU cooler supports Intel
®
LGA775 processors. The
following figures illustrate how the system fan effectively exhausts hot air through
multiple ventilation holes.
CPU Fan
Air Flow Direction
Air In
Air Out
Air Out
To Next Page
