MSI Hetis 945 - Connectors; IDE Connector: IDE1; Card Reader Connector: CR1

2-18
.
IDE Connector: IDE1
The mainboard has a 32-bit Enhanced PCI IDE and Ultra DMA 33/66/100 controller
that provides PIO mode 0~4, Bus Master, and Ultra DMA/33/66/100 function. The
connectors on the mainboard allows you to connect to the IDE devices: HDD & CD-
ROM.
2.7 Connectors
IDE1
Card Reader Connector: CR1
The mainboard provides a connector to connect the Card Reader on the Front
Panel.
CR1
