MSI MAG Z690 TOMAHAWK - JFP1, JFP2: Разъемы Передней Панели; PCI_E1~4: Слоты Расширения Pcie

20
Компоненты материнской платы
BAT1
PCI_E1~4: Слоты расширения PCIe
PCI_E1
PCI_E2
PCI_E3: P
PCI_E4: P
⚠
Внимание!
∙ 
MSI Graphics Card Bolster

∙ 
PCI_E1.
∙ 



JFP1, JFP2: Разъемы передней панели


1
2 10
9
+
+
+  
+
Power LED
HDD LED Reset Switch
Reserved
Power Switch
JFP1
1 HDD LED + 2 Power LED +
3  4 
5 Reset Switch 6 Power Switch
7 Reset Switch 8 Power Switch
9 Reserved 10 No Pin
1
JFP2
+
+


Speaker
Buzzer
1  2 Buzzer +
3  4 Speaker +
