14
Rear I/O Panel
Realtek Audio Console
After Realtek Audio Console is installed. You can use it to change sound settings to get
better sound experience.
∙ Device Selection
options. The check sign indicates the devices as default.
∙ Application Enhancement
guidance of anticipated sound effect for both output and input device.
∙ Main Volume
that you plugged in front or rear panel by adjust the bar.
∙ Jack Status
computer.
∙ Connector Settings
Auto popup dialog
When you plug into a device at an audio jack, a dialogue window will pop up asking you
which device is current connected.
Each jack corresponds to its default setting as shown on the next page.
⚠
Important
The pictures above for reference only and may vary from the product you purchased.
Jack Status
Connector Settings
Device
Selection
Main Volume
Application Enhancement
To Next Page
