Specifications
Continued from previous column
Storage
∙ 6x SATA 6Gb/s ports (From Z690 chipset)
∙ 4x M.2 slots (Key M)
▪ M2_1 slot (From CPU)
▫ Supports up to PCIe 4.0 x4
▫ Supports 2242/ 2260/ 2280/ 22110 storage devices
▪ M2_2 slot (From Z690 chipset)
▫ Supports up to PCIe 4.0 x4
▫ Supports 2242/ 2260/ 2280 storage devices
▪ M2_3 slot (From Z690 chipset)
▫ Supports up to PCIe 3.0 x4
▫ Supports up to SATA 6Gb/s
▫ Supports 2242/ 2260/ 2280 storage devices
▪ M2_4 slot (From Z690 chipset)
▫ Supports up to PCIe 4.0 x4
▫ Supports up to SATA 6Gb/s
▫ Supports 2242/ 2260/ 2280 storage devices
▪ M2_2~4 slots support Intel® Optane™ Memory
∙ Supports Intel® Smart Response Technology for Intel
Core™ processors
RAID
∙ Supports RAID 0, RAID 1 , RAID 5 and RAID 10 for SATA
storage devices
∙ Supports RAID 0, RAID 1 and RAID 5 for M.2 NVMe storage
devices
USB
∙ Intel® Z690 Chipset
▪ 
panel
▪ 

▪ 
back panel, 2 ports through the internal connector)
▪ 
∙ 
▪ 

Continued on next column

MSI MAG Z690 TOMAHAWK Specifications

General

Chipset	Intel Z690
CPU Socket	LGA 1700
Form Factor	ATX
Memory Slots	4
Maximum Memory	128 GB
SATA Ports	6
Network	2.5G LAN
Audio	Realtek ALC4080 Codec
Wi-Fi	No
Bluetooth	No
RAID Support	RAID 0, 1, 5, 10
M.2 Slots	3 x M.2 Gen4 1 x M.2 Gen3
