22
Overview of Components
3. If there is no EZ M.2 Clip installed, please install the supplied EZ M.2 Clip kit in the
M.2 slot according to your SSD length.
4.
5. Rotate the EZ M.2 Clip to fix the M.2 SSD.
30º30º
3
4
5
6. Put the M.2 SHIELD FROZR heatsink back in place and secure it.
6
6
6
6
6
6
