Introduction
1-5
Quick Components Guide
Component Function Reference
JWR1/2/3 ATX power connectors See p. 2-7
JKBMS1 Mouse/keyboard connector See p. 2-9
USB Connectors Connecting to USB devices See p. 2-10
COM A & COM B Serial port connector See p. 2-11
LPT1 Parallel port connector See p. 2-12
FDD1 Floppy disk drive connector See p. 2-13
JRMS1 Remote power on/off switch See p. 2-13
IDE1~ IDE2 Hard disk connectors See p. 2-14
JFP1/J23 Front panel connector See p. 2-15
JCD1/JAUX1/JPHN1 CD/AUX/Modem-in connectors See p. 2-16
CPU/PS/SYS FAN Fan power connectors See p. 2-17
JMDM1 Wake on ring connector See p. 2-18
JGS1 Power saving switch connector See p. 2-18
J18 IrDA infrared module connector See p. 2-19
J12 Chassis intrusion switch connector See p. 2-19
J22 Front panel audio connector See p. 2-20
JUSB1/JUSB2 Connecting to USB devices See p. 2-21
J24 D-Bracket connector See p. 2-25
JBAT1 Clear CMOS jumper See p. 2-27
J20 RDRAM over voltage jumper See p. 2-28
J17 Clear BIOS password jumper See p. 2-29
J16 BIOS flash jumper See p. 2-29
AGP Slot Connecting to AGP cards See p. 2-30
PCI Slots Connecting to expansion cards See p. 2-30
CNR Slot Connecting to expansion cards See p. 2-30
