z D-Bracket™ with one USB PC to PC port and one regular USB port
Connected to J24
Connected to JUSB1 pin header which is
implemented with USB PC To PC Networking
function
zz
zz
z D-Bracket™ with two regular USB ports
Connected to J24
Connected to JUSB1 or JUSB2 pin header
which DOES NOT support USB PC To PC
networking function
