2-7
Hardware Setup
Memory
DIMM1~DIMM2
(from left to right)
The mainboard provides two 240-pin non-ECC DDR II 667 DIMMs and supports up to
2GB system memory.
For more information on compatible components, please visit http://www.msi.com.tw/
program/products/mainboard/mbd/pro_mbd_trp_list.php.
Memory Population Rules
This mainboard supports DDR II 667 memory interface.
Each DIMM slot supports up to a maximum size of 2GB. Users can install either single-
or double-sided modules depending on their needs.
MSI Reminds You...
Make sure that you install memory modules of the same type and
density on DDR II DIMMs.
Slot Combination 1 Combination 2 Combination 3
DIMM1 64MB~1GB 2GB 0
DIMM2 64MB~1GB 0 2GB
Total Memory 128MB~2GB 2GB 2GB
